Gazelle Orange C7+ HMB 26″ L 26″ H7


A bike ride should be enjoyable. With that idea in mind, the Gazelle designers developed the Orange C7 HMB. With the Bosch Active Line Plus mid-motor (50 Nm) and seven Shimano gears, you can get anywhere. And with the hydraulic rim brakes you can come to a stop quickly and in a controlled manner. The neat finish increases comfort on all sides.
  • Stable frame in variant with and without top tube
  • You see more and stand out better thanks to the LED lighting
  • Leather grips and comfort saddle for a luxurious touch
  • More comfort thanks to suspension parts
  • Frame size 46cm
  • Wheel size 26″
Categories: ,



Frame/front fork

  • Frame: Stable, lightweight hydro-formed aluminium frame with 68.5° headset angle and 69.5° saddle tube angle for relaxed and comfortable riding. This is a low-step and spacious frame, single tube and lovely integrated cables.
  • Integrated cables: Yes
  • Fork: aluminium, springing in headset, lightweight
  • Chain case: Plastic
  • Rear carrier: Aluminum MIK system carrier


  • Rims: Mach1 ER-10, Double-walled aluminium for extra strong and efficient cycling performance
  • Spokes: Stainless steel, extra strong
  • Fender: plastic


  • Handlebar: aluminium, comfort curved model
  • Stem: Gazelle Switch, manually steplessly adjustable
  • Steer grip: Luxury leather handlebar grips for a sophisticated feel and extra comfort
  • Bell: Gazelle rotary bell


  • Crank: aluminum
  • Transmission: 38 x 18 teeth


  • Seatpost: Sprung


  • Lock type: AXA Defender, Ring lock with an option for a plug-in cable to attach your bike to a fixed object for extra protection against theft
  • Kickstand: drop-down rear stand, Ursus Mooi
  • Chain: extra strong, special for e-bike


  • Display: Bosch Intuvia LCD center
  • Controlled on handle: Yes
  • Sensors: rotation sensor; speed sensor; pedal force sensor
  • Engine: Bosch Active Line Plus 3.0 (50Nm), 36V
  • Charger: 4 Ah
