Gazelle Ultimate C5 HMB

3,750.00

High-quality multifunctional e-bike, taken care of down to the last detail. The first-class equipment including Nexus 5, Gates Beltdrive, Bosch Performance line and ergonomically shaped handles enable very sporty performance. Thanks to the integration of the battery, motor and the rigidity of the frame, the Ultimate C5 HMB drives wonderfully stable. The dynamic design, high comfort level and excellent handling make this bike the ideal companion for both long recreational rides and commuting.
Dynamic cycling with powerful support
High-quality Shimano disc brakes for optimal braking performance
Low maintenance due to the use of Nexus 5 and a belt drive
Integrated lighting, to see and be seen with
In stock in step through or cross bar frame.
Categories: ,

Description

Frame/front fork

  • Frame: Stable aluminum frame with 70.5° head tube angle and 71.5° seat angle geometry for sporty handling. Battery, motor and cables are harmoniously integrated into the frame. High-quality finish with an eye for detail.
  • Sitting position: Active
  • Cables integrated: Yes
  • Fork: aluminum, inner tube suspension, lightweight
  • Fork travel: 40 mm
  • Chain guard: Aluminum
  • Rear carrier: Gazelle commuter, aluminum

Wheels/tyres

  • Tires: Schwalbe Energizer Plus, 47-622
  • Tires anti-puncture: Yes
  • Rims: Dutch 19, Double-walled aluminum for extra strength and good driving characteristics
  • Rear hub: Shimano Nexus, 5-speed, freewheel
  • Spokes: stainless steel, extra strong
  • Mudguards: Aluminum

Send

  • Handlebar: Aluminum, slightly curved model
  • Stem: Infinitely adjustable with tools
  • Grips: Luxury leather grips for a refined feel and extra comfort
  • Handle type: Gazelle Aero leather
  • Brake levers: Shimano BL-MT200
  • Bell: Control Bell Decibel XXL

Braking/shifting

  • Gear: 5 Shimano Nexus
  • Rear brake: Disc brake with hydraulic actuation; Shimano BR-MT200, 2 piston 160 mm
  • Front brake: Disc brake with hydraulic actuation; Shimano BR-MT200, 2-piston 180 mm
  • Sprocket: Gates CDX
  • Shifter: Shimano Nexus 5
    • Crank: Aluminum
    • Front sprocket: 46
    • Rear Sprocket: 34, Gates CDX
    • Drive: Belt
    • Chain: Gates belt drive CDX, with Centertrack

    Saddle

    • Seatpost: Fixed
    • Saddle: Selle Royal Essenza Plus, Royalgel

    Relief

    • Headlight: Axa Blue Line 50, LED headlight, on/off switch via display
    • Headlamp light output (lux): 50
    • Headlight power supply: Battery
    • Rear lamp: Herrmans H-Cargo, LED battery power, on/off switch via display
    • Rear lamp power supply: Battery

    Other

    • Lock: AXA Defender, Frame lock with option for a mortise lock to secure your bike for extra security
    • Lock security level: ART ** certified
    • Stand: rear stand, Ursus Mooi

    System

    • Display: Bosch Intuvia LCD center
    • Display removable: Yes
    • Handle Control: Yes
    • Sensors: rotation sensor; speed sensor; pedaling force sensor
    • Engine: Bosch Performance Line (65 Nm), 36V
    • Battery: Low: Integrated in frame, High: Integrated in frame
    • Charger: 4 Ah
    • Battery: 500 Wh





























Specifications
